Discover the simple and scalable way to get pro AV performance in mid-size spaces up to 30' x 30' (9.1 x 9.1 m). The HDL310 is your no-compromise alternative to all-in-one sound bars that have limited microphone pickup range and custom AV systems that are costly and complex.
1 - USB 2.0 interface to computer or collaboration hub, type B
1 - Auxiliary out 3.5 mm single-ended stereo jack
1 - Auxiliary in 3.5 mm single-ended stereo jack
2 - Connections to microphone and speaker bars RJ-45
1 - Console Direct RJ-45 for connecting to network
1 - Input jack for power supply
INTEROPERABILITY
Plug and play compatibility with UC&C platforms including Microsoft Teams, Zoom, Google MeetTM, GoToMeeting®, Cisco Webex®, Blue Jeans, Lifesize®, RingCentral and more
Easy integration with third-party solutions such as Barco ClickShare, lecture capture systems and headset microphones with Voice Amplification Mode
OPERATING
Operating system
Windows® 8 and 10
Mac® OS X® 10 and 11
(Big Sur and Catalina)
Power
Power rating: universal switching 100-240V AC, 50-60Hz
Power consumption: <30W
Environmental
Operating temperature: 0° C to 40° C
Storage temperature: -20° C to 70° C, humidity 5–90% (noncondensing)
MANAGEABILITY
Includes Console Direct, which provides a continuous and secure connection to Nureva Console, our cloud-based device management platform
Console Direct security features
Secure IoT OS and system software with device-specific X.509 certificates and external services encrypted using 256-bit Transport Layer Security (TLS)
Information security management system (ISMS) aligned to ISO 27001
Built with Microsoft Azure, all data at rest is encrypted using 256-bit AES encryption, and data in transit uses TLS 1.2
Okta Identity Cloud for all identity and access management (IAM) services with OAuth2 protocols to identify and authorize users
CERTIFICATIONS AND COMPATIBILITY
Electromagnetic
FCC Part 15, Class A; ICES-003, Class A; CISPR 32 (EN55032), Class A; CISPR 35 (EN55035); CISPR24 (EN55024)
Safety
UL 62368; CAN/CSA-C22.2 NO.62368; IEC/EN62368; AS/NZS 62368; UL 60950; CAN/CSA-C22.2 NO.60950; IEC/EN60950; AS/NZS 60950
Compliance
RoHS, REACH, PoP (Persistent Organic Pollutants), WEEE compliance, California Proposition 65, EPA (TSCA-Toxic Substances Control Act) Restrictions
DIMENSIONS
Integrated microphone and speaker bar
Width: 60.0" (152.4 cm)
Height: 5.91" (14.9 cm)
Depth: 3.5" (9.0 cm)
Weight: 18.0 lb. (8.2 kg)
Connect module
Width: 8.7" (22.2 cm)
Height: 1.46" (3.7 cm)
Depth: 5.91" (15.0 cm)
Weight: 0.97 lb. (0.44 kg)
Shipping
Width: 64.75" (164.4 cm)
Height: 10.63" (27.0 cm)
Depth: 9.5" (24.1 cm)
Weight: 28.0 lb. (12.7 kg)
INCLUDES
Integrated microphone and speaker bars
Connect module, dark grey
Connect module mounting bracket, dark grey
Country specific power cable
Ethernet cables, CAT6 SSTP, 50' (15 m), Class 3 rated, black
USB Type A-B cable, 10' (3 m), VW-1 rated, black
Infrared remote with 2 AAA batteries
Documentation
WARRANTY
Integrated microphone and speaker bar and connect module – Standard 2-year limited hardware
